Volym i liter
Volym i liter
Använd draglisten för det volymspann ni önskar se. Klicka sen i t.ex. (material, omrörare, isolering etc.) för att slutligen klicka på FILTRERA, då visas endast de tankar som finns inom de krav ni angett.
Nytillverkad/Begagnad
Modell
Isolerad
Uppvärmning/kylning
Omrörare
Trycktank
-
-
- Tankar
28100 liter tank i Rostfritt 304
- 243,000,00 kr /st exkl moms
- Additional information: Pharmaceutical chemistry; Test pressure: + 4 bar; with 1 tank 1 connection in the upper bottom slightly bent Volumetric volume (L): 28.100 L Pressure in tank: vacuum Min. pressure (Bar): 0,40 Bar Max. temperature (°C): 50 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge:…
- Lägg till i varukorg
-
-
-
- Tankar
30000 liter tank i Rostfritt 304
- 184,000,00 kr /st exkl moms
- Additional information: Chemistry; 2 pipes inside the tank; 1 pipe outside the tank; Wall thickness of the lowest cylinder segment 3.0 mm Volumetric volume (L): 30.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing…
- Lägg till i varukorg
-
-
-
- Tankar
30000 liter tank i Rostfritt 304
- 204,000,00 kr /st exkl moms
- Additional information: Wool fat; Manhole diameter approx. 580 mm; metallic discoloration inside in the area of the upper bottom; some residues of previous content; manhole cover plated Volumetric volume (L): 30.000 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 70 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes…
- Lägg till i varukorg
-
-
-
- Nytillverkade tankar, Tankar
30 000 liter tank i rostfritt 304 eller syrafast 316
- 299,000,00 kr /st exkl moms
- Diameter 2500 mm Höjd mantel 6000 mm Höjd ben 500 mm Justerbara ben 5 st Konisk centrerad botten och topp. Material AISI 304 Total tömning med anslutning DN80 Rostfri märkskylt med teknisk data Ovel manlucka A5 Fratelli Laveggi 2st anslutningar på topp DN65 2st rostfria lyftöron Alla invändiga svetsar slipade platt, högglanspolerade Utvädig yta 2B matt/white Tillägg Material AISI 316…
- Lägg till i varukorg
-
-
-
- Tankar
30000 liter tank i Rostfritt 304
- 191,000,00 kr /st exkl moms
- Additional information: 2 loose bearing shells, Fe (galvanized); 1 manhole each approx. 350 x 445 mm in the front bottom; each stronger dents in the cylinder Volumetric volume (L): 30.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: horizontal Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents…
- Lägg till i varukorg
-
-
-
- Tankar
30000 liter tank i Rostfritt 304
- 227,000,00 kr /st exkl moms
- Additional information: Wool fat; Manhole diameter approx. 580 mm; metallic discoloration inside in the area of the upper bottom; Insulation jacket with dents and smaller sheet metal cutouts; some residues of previous content; manhole cover plated Volumetric volume (L): 30.000 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 70 °C Material wet parts: SS AISI 304 (V2A) Model:…
- Lägg till i varukorg
-
-
-
- Tankar
30395 liter tank i Rostfritt 304
- 401,000,00 kr /st exkl moms
- Additional information: Dairy; Double jacket with trickle ring - only suitable for pressureless cooling; dents in the double jacket; small cracks in the double jacket lining; connections partially cut off; 2 height-adjustable screws of the feet are missing; pipe end cut flush Volumetric volume (L): 30.395 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,50 Bar Min. pressure…
- Lägg till i varukorg
-
-
-
- Tankar
30400 liter tank i Rostfritt 304
- 336,000,00 kr /st exkl moms
- item available on order Article type: brand new storage tank - type K5-SL Volumetric volume (L): 30.400 L Max. density P (kg/m³): 1.350 Ra inner weld: 0,80 Finish stainless steel: 2B Pressure in tank: ATM - atmosferic Max. temperature (°C): 100 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 304L (V2A) Model: vertical Configuration: single-skin Heat exchanger:…
- Lägg till i varukorg
-
-
-
- Tankar
31000 liter tank i Rostfritt 304
- 460,000,00 kr /st exkl moms
- Additional information: Heating jacket around approx. 2.380 mm of the lower cylinder height; Manhole approx. 430 x 540 mm; Tanks are currently hanging in a transport frame made of Fe; 1 loose ladder bracket is included in the scope of delivery (would have to be welded on site if desired) Volumetric volume (L): 31.000 L Pressure in tank: ATM -…
- Lägg till i varukorg
-
-
-
- Tankar
31000 liter tank i Rostfritt 304
- 191,000,00 kr /st exkl moms
- Additional information: Fruit juice Volumetric volume (L): 31.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Outlet of tank: available
- Lägg till i varukorg
-
-
-
- Tankar
32000 liter tank i Rostfritt 304
- 367,000,00 kr /st exkl moms
- item available on order Article type: brand new storage tank - type TZN-SL Volumetric volume (L): 32.000 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Finish stainless steel: 2B Pressure in tank: ATM - atmosferic Max. temperature (°C): 60 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 304L (V2A) Model: vertical Configuration: single-skin Heat exchanger:…
- Lägg till i varukorg
-
-
-
- Tankar
32700 liter tank i Rostfritt 304
- 328,000,00 kr /st exkl moms
- item available on order Article type: brand new storage tank - type TZN-SL Volumetric volume (L): 32.700 L Max. density P (kg/m³): 1.000 Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Top type: conical 13 ° Shape of tank: cylindrical Bottom type: conical…
- Lägg till i varukorg
-
