3.650 mm - Processöverskott

- Tankar
- 1240 liter tank i Rostfritt 304
- 201,000,00 kr /st exkl moms
- Additional information: Make: Unimix; manhole DN 350; test papers in French; Outlet flange inner diameter 127 mm (reduced to outlet DN 40 DIN 11851 due to several fittings) Volumetric volume (L): 1.240 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 143 °C Material wet parts: SS AISI 304…
- Lägg till i varukorg
- Tankar
- 2500 liter tank i Rostfritt 304
- 59,000,00 kr /st exkl moms
- Additional information: adhesive production; frame Fe (with corrosion); rectangular opening appr. 490 x 590 mm in the upper bottom; some residues of previous content; motor-/gear is missing Volumetric volume (L): 2.500 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Agitator: yes Mobile…
- Lägg till i varukorg
- Tankar
- 3685 liter tank i Syrafast 316
- 164,000,00 kr /st exkl moms
- Additional information: Chemistry; 4 support brackets made of Fe; 1 vessel with insulation (insulation jacket Fe, lacquered; diameter outside approx. 1780 mm); some residues of previous content; Metallic discolouration inside Volumetric volume (L): 3.685 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS…
- Lägg till i varukorg
- Tankar
- 5000 liter tank i Rostfritt 304
- 104,000,00 kr /st exkl moms
- Additional information: Agriculture; Sheet metal cutout in the insulation jacket of the lower floor (underneath Fe plate); bump at the insulation jacket; scratches inside; Functionality of the double jacket not checked Volumetric volume (L): 5.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes…
- Lägg till i varukorg
- Tankar
- 5000 liter tank i Rostfritt 304
- 69,000,00 kr /st exkl moms
- Additional information: Detergents; Manhole cylinder appr. 310 x 440 mm; Height-adjustable screws of the feet are no longer available; screwed-on plastic fitting on the outlet (see photos); Device for level indicator outside (no longer complete); some residues of previous content Volumetric volume (L): 5.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical…
- Lägg till i varukorg
- Tankar
- 5700 liter tank i Syrafast 316
- 138,000,00 kr /st exkl moms
- Additional information: Pharmacy; Manhole DN 600; 1 heating coil originally located inside the vessel no longer exists; Metallic discolouration inside Volumetric volume (L): 5.700 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 6 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated Heat exchanger: no…
- Lägg till i varukorg
- Tankar
- 6100 liter tank i Syrafast 316
- 132,000,00 kr /st exkl moms
- Additional information: Chemistry; Insulation only around the cylindrical part of the tank; flanged to the outlet is a reducing fitting (reduced to an inside pipe diameter of 50 mm; fitting components made of plastic); 1 pump is included (see photos) Volumetric volume (L): 6.100 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS…
- Lägg till i varukorg
- Tankar
- 8000 liter tank i Rostfritt 304
- 77,000,00 kr /st exkl moms
- Additional information: Cip-tank in a brewery; pipelines inside the tanks; in the case of one tank the outlet is cut off; the other tank was re-welded in several places on the central cylinder weld; some residues of previous content Volumetric volume (L): 8.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration:…
- Lägg till i varukorg
- Tankar
- 9500 liter tank i Rostfritt 304
- 93,000,00 kr /st exkl moms
- Additional information: Molkerei; 2 Behälter innen im unteren Boden mit eingeschweißtem Blech; pipe end cut flush Volumetric volume (L): 9.500 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Agitator: yes Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate…
- Lägg till i varukorg
- Tankar
- 16500 liter tank i Rostfritt 304
- 100,000,00 kr /st exkl moms
- Additional information: Wine storage; 1 manhole approx. 320 x 420 mm in the cylinder; total height according to drawing; lower bottom with slope to the outlet with cup (for installation, an appropriate foundation would have to be built on site); upper bottom and top cylinder segment made of 1.4571 (Aisi 316); Tanks have been professionally cleaned and overhauled by the…
- Lägg till i varukorg
- Tankar
- 24000 liter tank i Rostfritt 304
- 165,000,00 kr /st exkl moms
- Additional information: Wine storage; 1 manhole approx. 320 x 420 mm in the cylinder; total height according to drawin); Tanks have been professionally cleaned and overhauled by the manufacturer in 2024; brand new residual drain valves, sampling valves and manhole seals were installed Volumetric volume (L): 24.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304…
- Lägg till i varukorg
